11 2027 Zephyr Exterior Features
EXTERIOR SIDES:
The sidewalls of your motorhome (Figure: 11-1) and the end caps are made of gel-coated fiberglass. To clean these fiberglass surfaces, use only warm water and a mild cleanser; gently wash with soft cloths. Use of stiff bristle brushes or other harsh abrasives might cause scratches on the fiberglass surfaces.
NOTE: Tiffin Motorhomes is NOT responsible for the weathering and/or oxidation of gel-coated surfaces.
Spacious storage compartments are located on the exterior sides of your motorhome. These external compartments provide ample additional space for your belongings while you are traveling. When stowing materials in these storage compartments, try to “balance” the resultant weight load from front to rear and from side-to-side. This will keep the center of gravity of the motorhome essentially unchanged and should not adversely affect the handling characteristics of the motorhome when it is in motion.
ELECTRIC CARGO TRAY (OPTIONAL):
There are two electric cargo trays (Figure: 11-2) in the cargo bay. To operate, open the cargo door housing the electric slide tray. Locate the switch (Figure: 11-3) on the inside of the cargo door. Use the OUT function on the switch to extend the slide tray from the coach. The IN function allows the electric slide tray to retract.
NOTE: The electric cargo tray can be operated from the driver and passenger side of the motorhome.
SECURITY LIGHTS:
On the motorhome, exterior security lights (Figure: 11-4) are standard features. A light is installed on the passenger side of the coach to help light that side of the Zephyr for added protection.
This light can serve as a “porch light” when the motorhome is parked and the awning is deployed so that various activities (e.g., sitting outside, grilling, visiting) at dusk and later can be enjoyed by the motorhome owners and their guests.
ROOF & LADDER (OPTIONAL):
The motorhome is manufactured with a fiberglass roof accessed by an optional ladder. Proper care and routine maintenance of the roof will ensure many years of trouble-free performance.
The (Optional) On-the-Go TM Ladder (Figure: 11-5) is a fully adjustable and collapsible ladder with safety locks at each rung for extra security. The ladder is designed to be used with the OEM-installed On the Go TM Receiver (Figure 11-6). The ladder can be used without the receiver as a lean-to ladder. For additional product information, for ordering replacement kits, or for ordering the On-the-Go TM Ladder (P/N: 2021126697), search online at www.lippert.com or contact Lippert Components directly by phone at 432-547-7378.
ELECTRIC STEPS:
The Zephyr is equipped with electric doorsteps (Figure: 11-7). The Step Switch (Figure: 11-8) to operate these steps is located in the door stairwell. When the power switch for the steps is in the ON position, open the door and the steps will automatically extend.
MIRRORS WITH BLIND SIDE MONITORING (BSM):
This motorhome is equipped with remote-controlled, exterior rear view mirrors. The mirror may be equipped with Blind Side Monitoring System, which is activated when a vehicle is beside your motorhome. (Red Oval) (Figure: 11-9).
Always adjust the mirrors for maximum rear visibility before driving. If another driver is to drive, be sure the mirrors are readjusted to accommodate the second driver. The mirrors are adjusted by using the multi-directional switch (Figure: 11-10) located on the dashboard. Select the mirror to be adjusted by pointing the arrow in the direction of that mirror.
Move the control in the direction of movement desired to obtain the best view for that mirror. The adjustment control (Figure: 11-10) moves the top half of both mirrors. The bottom half of each mirror is convex and is adjusted manually. Detailed instructions for these manual adjustments can be found in the manufacturer’s literature available in the Tiffin Knowledge Base Owner’s Hub. However, this brief overview of mirror adjustment can begin the process: The top portion of the mirror must be adjusted horizontally so that you can see your own motorhome in the one-inch surface closest to the motorhome. The remaining portion of the mirror now enables you to see the road behind you. The mirror must be adjusted vertically so that you can see the rear bumper on the bottom of the plane portion of the mirror. The convex mirrors must be adjusted horizontally so that you can see your own motorhome in 1/3 rd of the mirror. These convex mirrors must then be adjusted vertically to allow you to see any other vehicles alongside your motorhome.
These mirrors also contain heating elements to defog or deice the mirror glass during cold weather operation. The red ON/OFF switch for this feature is located by the adjustment control. Further adjustment of the mirror might be necessary at the swivel portion of the mirror arm.
OUTSIDE REFRIGERATOR ACCESS:
On the exterior of the motorhome, a hinged door with latch is provided to allow convenient access to the back of the kitchen’s refrigerator for servicing and repairs; see (Figure: 11-11).
PORTABLE FRIDGE/FREEZER:
The Zephyr features a Portable Fridge/Freezer designed for outdoor enthusiasts, RV travelers, and campers. The fridge/freezer is a compact, mobile appliance designed to keep food and beverages cold (refrigerated) or frozen while on the go. The Portable Fridge/Freezer features the following:
1. Temperature Range: Cools from -8°F to 50°F (-22°C to 10°C), suitable for both refrigeration and freezing needs.
2. Power Options: Operates on 12/24V DC (via car or RV) and 110V AC (wall outlet), providing flexibility for various power sources.
3. Energy Efficiency: Class A++ energy rating, ensuring low power consumption—ideal for solar setups and off-grid use.
4. Smart Control: Features an intuitive digital display and Bluetooth app control for easy temperature adjustments.
5. Robust Design: Built with reinforced corners, stainless steel hinges, and a removable lid for durability and easy cleaning.
6 Additional Features: Includes a USB port for device charging, LED interior light, bottle openers on both ends, and a 3-stage battery discharge protection.
This Portable Fridge/Freezer is installed in a dedicated passenger side exterior cargo bay as shown in (Figure: 11-12 and Figure: 11-13).
